Watching a beaker stir, on a phone, with nothing in the cloud

I had a question I couldn't shake: how much "lab perception" can you do on a phone, with no backend at all?

The pretext was a chemistry demo — watching someone stir a glass beaker with a metal rod and figuring out, in real time, what was going on. Object detection finds the beaker. Audio classification listens for the stir. Fusion glues them together: "stirring in vessel A", "impact while vessel A is present", "stirring complete".

The whole thing is a single index.html. Frames and audio never leave the device.

The pitch

You tap the page once. The browser asks for camera and mic in a single prompt. After that, three panes light up:

• A camera feed with detected vessels boxed and labelled vessel A, vessel B, vessel C...
• An audio spectrum and a YAMNet¹ readout: stirring 67%, impact 41%, etc.
• A structured event log: vessel_detected · A · 71% · cup, stir_start · yamnet 31% · vessel A, stirring_in_vessel · stir + vessel in view · vessel A, stir_end · yamnet 8% · vessel A.

If you don't grant permissions, or your camera is held by another app, the page falls back to a canned demo video so the rest of the system still has something to react to.

Three pipelines, one HTML file

Three loops run concurrently:

That's it. No worker pool, no inference server, no service workers. Two <script type="module"> imports off cdn.jsdelivr.net and you're running EfficientDet-Lite0 and YAMNet on a browser tab.

The vessel tracker

Naive object detection gives you boxes per frame, with no identity. If you want "vessel A" to stay "vessel A" while a hand reaches across, the vessel briefly leaves frame, or the camera is reframed, you need a tracker.

The one in index.html is a small IoU-greedy multi-object tracker with three states:

tentative  -> not yet confirmed; box but no event emitted
confirmed  -> hit threshold met; vessel_detected emitted
stale      -> confirmed but currently missing; vessel_lost emitted,
              still eligible for re-id within VESSEL_STALE_MS (5s)

The constants are tuned for "phone in your hand looking at a benchtop":

• VESSEL_HIT_FRAMES = 3 — confirm a sighting after about 100 ms.
• VESSEL_MISS_FRAMES = 20 — about 700 ms of misses before declaring lost.
• VESSEL_STALE_MS = 5000 — re-id window after going lost.
• VESSEL_IOU_ACTIVE = 0.30 / VESSEL_IOU_STALE = 0.15 — relaxed threshold when re-acquiring.

Labels are sequential letters (A, B, C, ...) and never reused within a session, even after a track expires. The next new vessel always gets the next letter, so the event log stays unambiguous if you read it back later.

YAMNet thinks stirring is a glockenspiel

Here is the part I did not see coming.

YAMNet¹ is trained on AudioSet, which has a perfectly reasonable label called Stir. The natural assumption is: stir a beaker, get high Stir confidence, done.

In practice, a metal rod tapping the inside of a glass beaker is acoustically a struck idiophone. Rhythmic metal-strike transients with ringing decay. AudioSet has labels for that too — but they live in the percussion family. YAMNet routes my beaker stirs through Glockenspiel, Vibraphone, Tubular bells, Wind chime, Chime, Bell, and Cymbal more often than Stir, Cutlery, or Dishes, pots, and pans.

So the regex accepts both families:

const STIR_NAME_RE = /\b(stir|cutlery|silverware|dishes,? pots|chink|clink|
  clatter|jingle|tinkle|glass|music|musical instrument|glockenspiel|
  vibraphone|tubular bell|chime|wind chime|bell|tuning fork|marimba|
  xylophone|rattle|cowbell|gong|cymbal)\b/i;

The displayed label is then remapped from the raw YAMNet category back into our task vocabulary, so the UI doesn't say "music 67%" while the user is stirring a beaker:

if (STIR_NAME_RE.test(topLabel)) yamnetTopLabel = "stirring"
else if (IMPACT_NAME_RE.test(topLabel)) yamnetTopLabel = "impact"
else yamnetTopLabel = topLabel.toLowerCase()

This regex is, embarrassingly, the most important line in the file.

Hysteresis and locked labels

A classifier producing one score every 500 ms will jitter. If you wired it directly to stir_start / stir_end, the event log would be a mess. Two pieces of state quiet it down:

• Schmitt-trigger hysteresis on the stir score. STIR_SCORE_ON = 0.25 to flip on, STIR_SCORE_OFF = 0.10 to flip off, and you have to hold those values for 2 frames on / 3 frames off (~1 s on, ~1.5 s off).
• Vessel label locking. When stir_start fires, the active vessel is captured into currentStirVesselLabel and held there until stir_end. If the active vessel switches mid-stir — because someone reaches across or because vessel B happens to score higher for a frame — the entire stir is still attributed to vessel A. The event log says one consistent thing per stir, which is what a human reviewer expects.

The impact event uses the same idea but simpler: a 600 ms debounce so a single Knock-class transient produces one event, not five.

The demo-mode fallback

The page assumes the worst about device permissions. There are three concrete failure modes I kept hitting on real phones:

• The user denies camera but allows mic, or vice versa. The page asks for them separately if the combined request was denied.
• Another app (Snapchat, Instagram, the system camera) is holding the camera. The track shows up, but is muted at start or never produces frames.
• The user is in a dark environment (lens covered, lights off).

A small watchdog reads a 16×16 pixel sample of the video frame every 500 ms, looks at the maximum channel value, and if it's below 10 for three consecutive seconds, prompts:

camera appears dark. No visible light has reached the camera for the last 3 seconds. The lens may be covered, or the device is in a dark environment.

[ swap to demo video ] • keep trying

If the user agrees, the visible <video> is repointed at demo.mp4, the audio source is swapped to a hidden video element's captureStream(), and the rest of the system keeps running unchanged. The fusion engine doesn't know or care whether it's looking at a live camera or a canned recording.

Why bother

Multimodal perception used to be a server farm. Object detection plus speech plus event reasoning meant Triton, GPUs, gRPC, and a lot of YAML. Doing the same thing in a browser tab, on a phone you already own, with the model weights coming off a CDN — that's still novel enough that it surprises me every time it works.

Also: it's a great party trick. Stir a beaker. Watch the page narrate what you're doing.
